Voltage/Frequencies (V/Hz)
|
220V,110V / 50Hz, 60Hz
|
|
Power (Watt)
|
≤550W
|
|
Max. Vacuum Flow (m3/h)
|
≤10.5m3/h(175L/min)
|
|
Ultimate Vacuum (KPa)
|
-92KPa(-700mmHg)
|
|
Noise Level dB(A)
|
≤60dB(A)
|
|
Ambient Temperature（℃）
|
5-40℃
|
|
Motor Protection Class
|
B
|
|
Cold Insulation Resistance
|
≥100MΩ
|
|
Dielectric Strength
|
1500V/50Hz 1min （No Breakdown）
|
|
Thermal Protector ℃
|
130±5℃(Automatic Reset)
|
|
Net Weight
|
8.7Kg
|
|
Installation Sizes
|
L203*W112mm(Installation hole∮7mm)
|
|
Product Dimensions
|
L244*W128*H190.8mm
|
|
Max Vacuum Restart
|
0KPa
|
|
Inlet/Outlet Connections
|
1/4-18FNPT
|
Applications: Dental & optical equipment, Blood & laboratory analyzers, Laboratory air Dryers, Aspirators, Respirators, Vacuum frames, Printing Equipment, Vacuum packaging equipment, Beauty and slimming equipment, Purging systems, Vacuum clamps, Automatic equipment.
|
